SPECIFICATION RANGE
& STATUS ON DELIVERY

1.Specifcation RangePlate
Thickness:1mm-200mm
Width:1000mm-4000mm
Length:1000mm-15000mm
Special Use: Mine
Supply Ability: 6000 Ton/Tons per Month
Grade: HARDOX400,HARDOX450,HARDOX500,NM360,NM400,NM450,NM500,B-HARD400,B-HARD450,B-HARD500

2. MOQ: 1 Ton

According to the performance and the requirements from clients, the status on delivery of steel plate can be hot rolled ^controlled rolling, normalizing, annealed tempering, normalizing + tempering, hardening + tempering, etc.
3. Packing: Standard Sea-worthy Packing or as Customers' Request
Port: Shanghai,Tianjin,Qingdao or as Required

4.Application

Construction Machinery,Mining Machinery,Metallurgical Machinery,Thermal Power Plant

Quantity(Tons)	1 - 6000	>6000
Est. Time(days)	30	To be negotiated

Product form

Chemical Composition:

Material	C	Si	Mn	P	S	Cr	Ni	Mo	Ti	Bt	Als	CEV
NM300	0.23	0.70	1.60	0.025	0.015	0.70	0.50	0.40	0.050	0.0005-0.0006	0.010	0.45
NM360	0.25	0.70	1.60	0.025	0.015	0.80	0.50	0.50	0.050	0.0005-0.0006	0.010	0.48
NM400	0.30	0.70	1.60	0.025	0.010	1.00	0.70	0.50	0.050	0.0005-0.0006	0.010	0.55
NM450	0.35	0.70	1.70	0.025	0.010	1.10	0.80	0.55	0.050	0.0005-0.0006	0.010	0.60
NM500	0.38	0.70	1.70	0.020	0.010	1.20	1.00	0.65	0.050	0.0005-0.0006	0.010	0.65
NM550	0.38	0.70	1.70	0.020	0.010	1.20	1.00	0.70	0.050	0.0005-0.0006	0.010	0.72
NM600	0.38	0.70	1.90	0.020	0.010	1.50	1.00	0.70	0.050	0.0005-0.0006	0.010	0.76

Mechanical Properties:

Material	Tensile MPA	Elongation %	Impact energy -20ºC	HBW
NM300	≥1000	≥14	≥24	270-300
NM360	≥1100	≥12	≥24	330-390
NM400	≥1200	≥10	≥24	370-430
NM450	≥1250	≥7	≥24	420-480
NM500	≥1250	≥7	≥24	≥470
NM550	≥1250	≥7	≥24	≥530
NM600	≥1250	≥7	≥24	≥570

Grades of Wear Steel Plate

Steel Standard	Steel Grades
Sweden	HARDOX400	HARDOX450	HARDOX500	HARDOX600	SB-50	SB-45
Germany	XAR400	XAR450	XAR500	XAR600	Dillidur400V	Dillidur500V
Bao Steel	B-HARD360	B-HARD400	B-HARD450	B-HARD500
China	NM360	NM400	NM450	NM500
Finland	RAEX400	RAEX450	RAEX500
Japan	JFE-EH360	JFE-EH450	JFE-EH500	WEL-HARD400	WEL-HARD500
Belgium	QUARD400	QUARD450	QUARD500
France	FORA400	FORA500	Creusabro4800	Creusabro8000
